M8
RONA
8547901000
100PCS
M8 Cable Assembly Product Applications
These M8 cable assemblies are designed for automation technology and industrial environments, providing external interconnection solutions for signal and power transmission in electronic equipment. They are suitable for both stationary and mobile applications and are intended for indoor installation.
Features
Flame-retardant cables compliant with IEC 60332-1 standard.
Excellent resistance to abrasion and oil, with superior performance offered by the robust PUR (Polyurethane) jacket.
Long service life, ensuring reliable operation over time.
High flexibility for easy installation and effortless reconfiguration or replacement of connected equipment.
Available in a variety of standard lengths and jacket options to meet diverse application needs.
Cables comply with UL safety standards.
Conforms to the RoHS 2.0 directive for environmental safety.
High-flex versions are available, capable of withstanding over 5 million cycles in cable carrier applications, making them particularly suited for dynamic, moving applications.
Cable Construction / Performance
| Item | Fixed Type | High-Flex Type |
| Conductor Gauge | 3X0.25mm² (14/0.15 Bare Copper) | 3X0.25mm² (32/0.10 Bare Copper) |
| 4X0.25mm² (14/0.15 Bare Copper) | 4X0.25mm² (32/0.10 Bare Copper) | |
| Insulation Material | HDPE | HDPE |
| Core Wire Color | 3-core: Blue / Brown / Black | 3-core: Blue / Brown / Black |
| 4-core: Blue / Brown / Black / White | 4-core: Blue / Brown / Black / White | |
| Sheath Material | PVC / PUR (Optional) | PUR |
| Sheath Color | Black (RAL9004) | Black (RAL9004) |
| Cable Outer Diameter | 3-core: 4.0±0.3mm | 3-core: 4.5±0.3mm |
| 4-core: 4.2±0.3mm | 4-core: 4.8±0.3mm | |
| Coding | A Code | A Code |
| Connector Type | M8 3-pin / 4-pin | M8 3-pin / 4-pin |
| Molded Type | Straight | Straight |
| Temperature Range | Fixed Application: -40℃ ~ 80℃ | Fixed Application: -50℃ ~ 80℃ |
| During Installation: -5℃ ~ 60℃ | During Installation: -40℃ ~ 60℃ | |
| Drag Chain Application: -20℃ ~ 60℃ | ||
| Protection Rating | IP67 | IP67 |
| Min. Bending Radius | 7.5D (D = Cable Diameter) | 7.5D (D = Cable Diameter) |
Application
Industrial Automation Systems: Widely used for connecting sensors, actuators, controllers, and other devices on production lines and machinery.
Control Cabinet Wiring: Facilitate internal and external connections within control panels and electrical enclosures.
Robotics: Provide reliable connections for robotic arms, end-effectors, and mobile robotic platforms, especially the high-flex versions.
Conveyor Systems: Ideal for sensor and power connections in both fixed and moving sections of conveyor belts.
Packaging and Material Handling Equipment: Ensure stable signal and power transmission in high-cycle machinery.
Fixed Installation: Suitable for permanent wiring within equipment or between stationary machines where minimal movement is expected.
Mobile Applications: Specifically designed for use in automated guided vehicles (AGVs), cable carriers, and other moving machinery, capable of withstanding continuous flexing.
