M12
RONA
8547901000
100PCS
M12 Cable Assemblies
Deployed in industrial automation, these cable assemblies provide external connectivity for signal and power transmission in electronic equipment. They support both fixed and mobile applications, and are rated for indoor use.
Features
Flame Retardant: The cable complies with the IEC 60332-1 flame retardant standard.
Durable & Robust: Excellent resistance to abrasion and oil, with superior performance offered by the PUR jacket.
Long Service Life: Designed for extended operational longevity.
Flexible Application: Enables easy connection and replacement of equipment.
Multiple Configurations: Available in a variety of lengths and jacket options.
Safety Certified: Cable compliance with UL safety standards.
Environmental Compliance: Conforms to the RoHS 2.0 directive.
High-Flex Option: A high-flex version is available, capable of withstanding over 5 million flexing cycles in cable carrier applications, making it ideal for dynamic movement.
Cable Construction / Performance
| Item | Fixed Installation | High-Flex |
| Conductor Gauge | 4X0.34mm² (19/0.15 bare copper) | 4X0.34mm² (42/0.10 bare copper) |
| 5X0.34mm² (19/0.15 bare copper) | 5X0.34mm² (42/0.10 bare copper) | |
| Insulation Material | HDPE | HDPE |
| Core Color | 4-core: Blue / Brown / Black / White | 4-core: Blue / Brown / Black / White |
| 5-core: Blue / Brown / Black / White / Gray | 5-core: Blue / Brown / Black / White / Gray | |
| Jacket Material | PVC / PUR (Optional) | PUR |
| Shielding | Braided (Tinned Steel), Optional | None |
| Braid Density | ≥ 85% | None |
| Jacket Color | Black (RAL9004) | Black (RAL9004) |
| Cable OD | Unshielded: 4-core 4.5±0.3mm; 5-core 4.8±0.3mm | 4-core 5.10±0.30mm |
| Shielded: 4-core 5.0±0.3mm; 5-core 5.4±0.3mm | 5-core 5.60±0.30mm | |
| Coding | A-Code | A-Code |
| Connector Type | M12, 4-pin / 5-pin | M12, 4-pin / 5-pin |
| Molded Style | Straight / Right-Angle | Straight / Right-Angle |
| Temperature Range | Fixed: -40°C ~ +80°C | Fixed: -50°C ~ +80°C |
| Installation: -5°C ~ +60°C | Installation: -40°C ~ +60°C | |
| Flexing: -20°C ~ +60°C | ||
| IP Rating | IP67 | IP67 |
| Min. Bending Radius | 7.5 x D (D = Cable Diameter) | 7.5 x D (D = Cable Diameter) |
Industrial Automation: Widely used in connecting sensors, actuators, and controllers on automated machinery and production lines.
Signal & Data Transmission: Provides reliable connections for control signals and industrial communication networks (e.g., PROFINET, EtherCAT).
Power Supply: Delivers power to a wide range of industrial electronic devices and small motors.
Fixed Installations: Ideal for control cabinet wiring, equipment racks, and other static applications.
Dynamic & Mobile Applications: Specifically designed for continuous use in cable carriers, robotic arms, and other moving machinery.
Indoor Industrial Environments: Suited for factory floors, control rooms, and other indoor settings requiring robust connectivity.
