REUST 18G1.5
RONA
85444929
Product Overview
These high-performance flexible cables are specifically designed for use in harsh industrial environments, including crane systems, port machinery, and waste-to-energy plants. Engineered for durability and reliability, they are ideal for festooning and reel applications on lifting equipment, hoists, and automated handling systems.
Constructed with premium-grade materials, the cables feature exceptional flexibility, abrasion resistance, and resistance to oils, chemicals, and mechanical stress. Their robust design ensures stable power transmission and signal integrity even under continuous bending, torsion, and dynamic loads. Suitable for power, control, and data transmission, these cables enhance operational efficiency and safety in heavy-duty applications.
▍Product structure
| Model | REUST 18G1.5 |
| Conductor | Multiple finely stranded bare copper wires, compliant with VDE 0295, Class 5 conductor |
| Insulation | High-strength TPE mixture |
| Core Identification | Black core with consecutive white numerical markings |
| Outer Sheath | TMPU |
| Outer Sheath Color | Red/Black |
| Working Voltage | 600/1000V |
| Test Voltage | 3500V |
| Minimum Bending Radius (Mobile Installation) | Approximately 10x D (outer diameter of the cable) |
| Minimum Bending Radius (Fixed Installation) | Approximately 5x D (cable outer diameter) |
| Temperature Range (Mobile Installation) | -35°C to +90°C |
| Temperature Range (Fixed Installation) | -40°C to +90°C |
| Weather Resistance | Excellent UV resistance, suitable for both indoor and outdoor use |
| Flame Retardant Properties | Compliant with IEC 60332-1 |
| Bending Life | Approximately 2 million cycles (for specific bending life calculations, please contact our sales engineers) |
| Certifications | CE, EAC, ROHS |
High flexibility for repeated bending and rolling
Resistant to oils, chemicals, and extreme temperatures
Reinforced shielding for EMI protection (if applicable)
Long service life under demanding conditions
Overhead cranes and gantry systems
Port container handlers and ship loaders
Waste incineration plants and recycling cranes
Other heavy industrial automation systems
Q: What is the cable's current rating?
A: Each 2.5 mm² conductor supports a continuous current of up to 25A at 60°C (per IEC 60228), with the total capacity dependent on the number of active cores and ambient temperature.
Q: Can the cable be used in extreme temperatures?
A: Yes, it operates reliably between -40°C and +100°C, making it suitable for cold storage facilities, foundries, and outdoor winter construction sites.
Q: What is the minimum bending radius?
A: The minimum bending radius is 10x the cable's outer diameter (typically 120mm for a 12mm diameter cable), ensuring flexibility in tight drum configurations without damaging the conductors or sheath.
Q: Does the cable require grounding?
A: Yes, grounding the optional shield and armor (if installed) is essential for safety and to minimize EMI, in compliance with OSHA 1910.304 and IEC 61140 standards.
Q: Is the cable available with custom configurations?
A: Yes, we offer custom core counts (8–24 cores), conductor sizes (1.5–10 mm²), and shielding options (braided or foil) to meet specific project requirements, such as enhanced EMI protection for sensitive lifting controls.
