HFMV 10*2.5mm2
RONA
85444929
500m
Product Description
Designed for high-stress dynamic environments, the HFMV 10x2.5mm² Low Voltage Power Cable is engineered to deliver uninterrupted power transmission within continuous-flex cable tracks and energy chains. Unlike standard fixed-installation cables that suffer from core rupture and "corkscrewing" under repetitive movement, this HFMV series utilizes a highly optimized stranding pitch and extra-fine bare copper conductors (Class 6).
Operating at a robust 0.6/1kV voltage rating, this 10-core (2.5mm² per core) unshielded cable is the most cost-effective and structurally reliable solution for multi-axis power distribution where severe Electromagnetic Interference (EMI) is not the primary concern, but maximum physical flexibility and dielectric strength are critical.
▍Specification
| Parameter | Specification |
| Part Number / Model | HFMV (Unshielded Continuous-Flex Power Cable) |
| Core Configuration | 10 Cores × 2.5 mm² (Precision-stranded for dynamic tension relief) |
| Nominal Voltage (U₀/U) | 0.6 / 1 kV (Low Voltage AC) |
| Conductor Design | Extra-fine bare copper strands (IEC 60228 Class 6 compliant) |
| Insulation Material | High-grade electrically resilient PVC compound |
| Outer Sheath / Jacket | Specially formulated flexible industrial PVC |
| Shielding | Unshielded (Optimized for maximum bendability and weight reduction) |
| Flame Retardancy | Self-extinguishing and flame retardant (EN 60332-1) |
| Sheath Color | Typically Black or Grey (UV and mildly oil-resistant) |
▍Advantages
Elimination of Corkscrewing Effect:
By employing a short lay-length in the cabling process, the mechanical load is evenly distributed across all 10 cores during continuous bending. This structural engineering prevents the internal cores from twisting out of formation, drastically extending the cable's lifecycle in automated tracks.
Low-Friction PVC Jacket:
The extruded PVC outer sheath is formulated to possess a low coefficient of friction. This prevents the cable from adhering to the drag chain partitions or adjacent cables, minimizing heat generation and jacket abrasion during high-speed, multi-shift operations.
High Current Carrying Capacity (10x2.5mm²):
With ten individual 2.5mm² cross-section cores, this cable provides exceptional current handling capabilities. It allows engineers to consolidate multiple power feeds into a single, space-saving drag chain layout, ideal for complex robotic setups or multi-motor automated systems.
▍Widely used in:
Gantry Robots & Multi-Axis Machining Centers:
Reliable multi-line power supply to servos, actuators, and moving tool heads.
Automated Storage and Retrieval Systems (ASRS):
Durable wiring for high-speed warehouse logistics equipment.
Conveyor & Transfer Lines:
Supplying stable 0.6/1kV power in factory automation networks.
Woodworking & Packaging Machinery:
Where continuous flexing cycles demand a robust, unshielded energy chain cable.
Wherever high-flexibility cables are essential for moving equipment within cable carriers (drag chains), our HF cables provide the resilience needed for smooth, uninterrupted operation.
