HFMVP 8G1.5
RONA
85444929
500m
Product Overview
Upgrade your dynamic systems with the HFMVP 8G1.5 Shielded Drag Chain Power Cable, specifically engineered for high-stress, continuous motion environments. Designed for demanding industrial automation, this 8-core (1.5mm²) flexible cable delivers highly stable power transmission at a 0.6/1kV low-voltage rating.
The robust, specially modified PVC outer sheath provides exceptional mechanical protection against daily abrasion, friction, and typical industrial chemicals. Equipped with a high-density tinned copper braided shield, it guarantees uninterrupted signal and power integrity by blocking out severe Electromagnetic Interference (EMI). It is the ultimate wiring solution for CNC machinery, automated production lines, and robotic energy chains.
▍Specification
| Parameter | Specification |
| Product Model | HFMVP |
| Cable Configuration | 8G1.5 (8 Cores × 1.5 mm², includes 1 Green/Yellow Earth Wire) |
| Voltage Rating | 0.6 / 1 kV (Low Voltage AC) |
| Conductor Material | Ultra-fine bare copper strands (Class 6, optimized for dynamic flexing) |
| Outer Sheath Material | Specially formulated industrial PVC (Wear and moisture resistant) |
| Shielding Type | Tinned copper wire braiding (High EMI/RFI attenuation) |
| Fire / Flame Resistance | Compliant with EN 60332-1 standards |
| Approvals & Certifications | CE, RoHS, VDE, EAC approved |
▍Key Features
Built for Continuous Flexing (High Bending Life):
Constructed with precision-stranded fine copper wires and an optimal lay length, this cable prevents inner core rupture during repetitive back-and-forth movements in fast-paced cable tracks.
Superior EMI Protection:
In modern automated settings, electrical noise can severely disrupt machine operations. Our tightly woven shielding acts as a robust barrier, ensuring clean, distortion-free power delivery to your servo motors and sensitive equipment.
Durable Industrial PVC Jacket:
The engineered PVC sheath is not merely flexible; it is highly resistant to abrasion, mechanical impact, and minor oil exposure. It glides smoothly within cable drag chains, significantly reducing friction and wear over time.
Maximum Safety & Compliance:
Manufactured to meet stringent international safety guidelines, including EN 60332-1 flame retardant standards, providing you with a safe and reliable 0.6/1kV power distribution solution.
▍Widely used in:
Robotics & Automated Handling Systems:
Reliable power feeding for moving joints, robotic arms, and tracks.
CNC Machine Tools:
Supplying uninterrupted power to milling, cutting, and turning centers.
Automated Packaging & Assembly Lines:
Perfect for high-speed energy chain systems requiring constant movement.
Conveyor Systems & Automated Parking:
Delivering long-lasting durability in continuous looping mechanisms.
Wherever high-flexibility cables are essential for moving equipment within cable carriers (drag chains), our HF cables provide the resilience needed for smooth, uninterrupted operation.
